Instructions for the installer
The appliance is fitted with a terminal board at the rear for electrical
connections (see following diagram). To access, remove the rear cover.
For operation on 380-415V3N ∼ : use a
H05V2V2-F-type five-core cable (5 x 2.5
mm
2
).
For operation on 220-240V ∼ : use a
H05V2V2-F-type three-core cable (3 x 6
mm
2
).
The end to be connected to the appliance
must have an earth wire (yellow-green) at
least 20 mm longer than the others.
