6.4 Cleaning the filter unit
• Periodically inspect the filter unit (ref A fig. 6-04) and, if necessary
clean it under running water (at room temperature), using a stiff brush.
To remove the filter, grip the tabs, turn anticlockwise and lift upwards;
• push the centre filter (ref. A fig. 6-05) from the underside to remove it
from the micro-filter;
• separate the two parts which make up the plastic centre filter by press-
ing the body of the filter in the zone shown by the arrows (ref. B fig.
6-05);
• remove the centre filter by lifting it upwards.
• after cleaning, remount the filter unit, joining the two parts comprising
the centre filter by pushing slightly until they click into place; insert the
centre filter into the micro-filter (see fig. 6-05). Reposition the filter unit
(ref. A fig. 6-04) into its seat, turning it clockwise until it locks.
Fig. 6-04
Fig. 6-05
USER INSTRUCTIONS
37
EN
