6.2 NATURE AND FREQUENCY OF MAINTENANCE CHECKS AND
INTERVENTIONS
In the manual, the description of the various maintenance operations is often associated to the
symbols described below.
6.3 REPLACING SEALING BLADE
In order to replace the sealing blade, turn off and unplug the machine and follow the
instructions below:
• Unscrew the three screws 1 blocking the blade.
• Remove the worn or damaged sealing blade 2.
• Thoroughly clean the seat in which the sealing blade is positioned.
• Insert the insulating PTFE 3 inside the central clamp 4.
• Insert the new sealing blade, properly blocking it in the middle of its seat.
• Trim of the sealing blade flush with the slot of the pistons 5 and 6.
• Complete insertion of the sealing blade along the whole seat.
• Use a screwdriver to push the piston 5 all the way down towards the head of the blade so
• General electric isolator
24 months
• Emergency button
12 months
• Indirect contact guard (equipotential protection system)
36 months
• Safety contactors
12 months
• Eye check of overall status of safety guards located on the machine
which impair the operator from reaching moving parts
12 months
• Safety micro-switches.
12 months
•Hinges
5 years
Identifies an eye check on the state of wear or proper
operation of a component.
Identifies an operation for cleaning a component.
Identifies a mechanical intervention (regulations, repairs,
replacements) to be carried out on the component.
Identifies a mechanical tensioning intervention to be carried
out on the component.
Identifies a lubrication intervention with synthetic oil.
Identifies a lubrication intervention with grease.
