CARBIDE FLAIL CUTTER SET-UP
Note:Thefollowingdiagramsareintendedtoguideyoutroughgeneralcutterset-ups.
QuantitiesofCuttersandSpacersmayvary,dependingonthenishyoudesire.  CF2616™ CF2618™
Placingmorecuttersoneachshaftwillprovideasmoothernish.Addingspacerswill
giveamorecoarsenish.Aligningthecutterswillcreateagroovepattern.
CF2516™ CF2515™
GROOVEFINISH  GENERALFINISH
Align Cutters and Spacers 90 CUTTERS (approx.)
2 Spacers per Cutter
FINEFINISH  SUPER-FINEFINISH
114 CUTTERS (approx.) 160 CUTTERS (approx.)
1 Spacer per Cutter 0 Spacers
Flip charts upside-down for set-up of other side of drum.
STEEL CUTTER SET-UP
   SUPER-FINEFINISH  456SteelCutters
   (Note:QuantityofCuttersmayvary)
HS1008™ HS1000™
Bushed Drum Drum
  P/N:65050        P/N:65051
Offset with
spacers to
prevent
grooving.
Drum
P/N:65051
Bushed Drum
P/N:65050
