11
Service
WIRING DIAGRAM
REF# PART# DESCRIPTION QUANTITY
1 GPS Antenna (part of speedometer) 1
2 48-147 Negative Battery Cable 1
3 33-216 Battery 1
4 50-359 Oil Temperature Light 1
5 50-323 Red Battery Cable 1
6 13-488 Key Switch 1
7 77-261 40 Amp Circuit Breaker 1
8977 Red Circuit Breaker Boot 1
8 Solenoid 1
9 77-207 Buzzer 1
10 33-084 Magnetic Coil 1
11 33-509 Master Boom Switch 1
12 Right Boom
15-725 Mount Panel End 1
15-727 Rocker - No light 1
13 Left Boom
15-729 Mount Panel Middle 1
15-727 Rocker - No light 1
14 Pump
15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-731 Rocker - Amber 1
15 Cruise
15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-732 Rocker - Green 1
16 Lights
15-725 Mount Panel End 1
15-727 Rocker - No light 1
17 32-014 Lights 2
18 33-480 Pressure Switch 1
19 16-998 Spray Pump 1
20 12-017 Hour Meter 1
21 Engine Block 1
22 20-730 GPS Speedometer 1
23 14-292 Seat Switch 1
24 20-733 10AMP Circuit Breaker 1
8877 Red Circuit Breaker Boot 1
25 9016 Weather Pack 1
26 9017 Terminal 2
9018 Seal 2
20-579 Wire Harness 1
To Next Page
