HOSE REEL MOUNT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 15-749 Hose Barb
3
/
4
1
2 9032-110
3
/
4
" Black Hose 110" 1
18-040 Hose Clamp 2
3 16-129 Manual Rewind Hose Reel 1
4 HB-516-18-150 Bolt
5
/
16
-18 x 1
1
/
2
4
HW-516 Washer
5
/
16
4
HNTL-516-18 Lock Nut
5
/
16
- 18 4
5 16-295 Hose Fitting
3
/
4
1
6 Hose Reel Mount bracket (part of machine) 1
7 18-249 Barb Fitting 1
8 HB-516-18-175 Bolt,
5
/
16
-18 x 1
3
/
4
4
HNFL-516-18 Flange Lock Nut,
5
/
16
- 18 4
1. Wear protective clothing when draining the tank and taking apart the lines.
2. Drain tank and spray system in a safe and approved method insuring that no chemical or water remain
in tank as you will be taking apart lines.
3. Remove key from ignition, set park brake and block wheels.
 
5
/
16
- 18 x 1
1
/
2
and
four
5
/
16
- 18 lock nuts to hold in place. Tighten bolts.
 
6. Place the 16-295 Hose Fitting into the Hose reel center.
7. Remove the blank cover from the ball valve by the manifold valve and place the 15-749 Hose Barb.
Tighten clamp.
 
place with the two 18-040 clamps.
9. Be sure all clamps and hardware are tight before using.
HOSE REEL ADJUSTMENTS
OPERATIONAL CHECK:
 󰀨
2. Let the hose retract.
 󰀨
4. Continue pulling the hose, no more than one revolution, until no clicking is heard. Hose should rewind when tension
is removed.
HOSE REPLACEMENT PROCEDURE:
1. Facing swivel, turn the hose drum clockwise until all of the hose is removed from the drum and the drum is held by
locking mechanism. Make sure spring is locked.
2. Remove hose clamps and disconnect hose from swivel. Remove old hose.
3. Insert new hose through roller guide, connect to swivel and reinstall hose clamps. Use spring guard over hose to
protect the hose from being cut by the drum.
4. Remove check ball from old hose and install on replacement hose.
5. Carefully, keeping the tension on the hose, pull the hose to release the locking mechanism. Let the hose wind on
the drum.
