Parts
31
ENGINE AND PUMPS PARTS LIST
REF# PART# DESCRIPTION QUANTITY
20 20-632 Long Exhaust Shield 1
21 23-133 90° Adjustable Elbow 1
22 20-569 Centering Arm 1
23 15-702 Adapter 2
24 HB-38-16-175 Bolt
3
/
8
-16 x 1
3
/
4
1
HW-38 Washer
3
/
8
1
HNTL-38-16 Lock Nut
3
/
8
-16 1
25 14-266 Ball Bearing 1
26 18-270 Spacer 1
27 18-266 45° Elbow 1
28 11-021 Engine Mount 4
HWL-38 Lock Washer
3
/
8
8
HN-38-24 Nut
3
/
8
- 24 8
29 20-566 Spring Mount 1
30 20-576 Oil Filter Assembly 1
20-576-01 Replacement Filter
31 20-581 Idler Arm 1
32 HB-12-13-300 Bolt
1
/
2
- 13 x 3 1
HMB-12-14 Machine Bushing
1
/
2
x 14GA 2
HWL-12 Lock Washer
1
/
2
1
HN-12-13 Nut
1
/
2
-13 1
33 HG-14-28-180 Grease Zerk
1
/
4
-28 x 180° 1
34 HB-716-14-150 Bolt
7
/
16
- 14 x 1
1
/
2
4
HWL-716 Lock Washer
7
/
16
4
35 20-541 Engine Plate 1
36 HKSQ-14-150 Square Key
1
/
4
- 1
1
/
2
1
37 15-703 Pulley 1
38 20-533 Left Oil Cooler Mount 1
39 20-594 Guide Disk 2
40 20-636 Outlet Exhaust Shield 1
41 23-145 O-ring 1
