Accessories
83
30-009 MANUAL HOSE REEL DRAWING
REF# PART# DESCRIPTION QUANTITY
1 16-129-11 Disc 17
1
/
2
1
2 16-906-25 Retaining Ring 2
3 16-906-22 Axle Assembly
3
/
4
1
4 HB-38-16-100 Bolt
3
/
8
- 16 x 1 4
5 HW-38 Washer
3
/
8
4
6 16-906-27 Trim, Drum Edge 1
7 16-906-21 Drum Center 1
8 16-906-20 Disc 17
1
/
2
, Crank Side 1
9 HWL-516 Lockwasher
5
/
16
8
10 HB-516-18-075 Bolt
5
/
16
- 18 x
3
/
4
8
11 16-129-09 Crank Assembly
3
/
4
1
12 16-129-10 Brake Assembly
3
/
4
1
13 HNTL-38-16 Lock Nut
3
/
8
- 16 4
14 HNTL-516-18 Lock Nut
5
/
16
- 18 2
15 16-129-03 Lock Pin Assembly 1
16 HB-516-18-075 Bolt
5
/
16
- 18 x
3
/
4
2
HW-516 Washer
5
/
16
2
17 16-129-07 Frame Assembly 1
18 16-906-08 Mounting Pillow Block (Bottom) 2
19 16-906-24 Bearing 2
20 16-906-07 Mounting Pillow Block (Top) 2
21 16-906-23 Swivel Assembly
3
/
4
1
16-906-30 Seal Kit ( For 16-906-23 ) 1
