31
This feature will copy the programmed data and parameters in the master unit to slave units. It copies the parameters and memory program settings.
Use optional
1.
30Q183601 cloning cable, connect the cable between the data jacks on both master and slave .
Press and hold
2.
key, then press key to enter into cloning mode, LCD displays "CLONE".
Press master
3.
unit's key, LCD displays "SD XXX", "XXX" indicates data volume in transmitting. Slave unit displays "LD XXX", "XXX" indicates
received data volume. When the transmission is successfully finished, the master and slave unit both display "PASS". Turn off the power,
disconnect the cable and repeat step 2 to step 3 operations to clone the next slave unit.
10
Cable Clone
After master radio entering cloning mode, you can clone many radios by repeating step2 and step3. If the data is not successfully transmitted, turn off both units,
make sure the cable connection is correct and repeat the entire operation from the beginning.
