• 43 •
REPLACING THE PRINTER PAPER
Open the print cover (ref 3, Fig. 40), and replace the paper roll
with a new one.
Use only heat-sensitive paper of the type described below.
Paper width: 2.2 in (58 mm).
Maximum paper roll diameter: 1.6 in (40 mm).
INFO
From the MAIN MENU:
Select the INFO, the following screen will be displayed:
SW V.: Software version.
Tank refrigerant:
Total: total amount of refrigerant in the storage
tank.
Available: quantity of refrigerant available in the
storage tank.
OIL: sum of the quantity of PAG and OIL2\DYE in the PAG
and OIL2\DYE containers.
Used: quantity of OIL in the USED OIL container.
Ambient temperature: ambient temperature near the
service station.
Tank temperature: refrigerant storage tank temperature.
Tank pressure: refrigerant storage tank pressure.
A/C pressure: pressure in the service hoses.
Press ESC to return to MAIN MENU.
R134a
mm/dd/yyyy
hh:mm
xxxxxxx
AUTOMATIC MANUAL SERVICES
SETUP
MAINTENANCE INFO
R134a INFO
Tank refrigerant
Total: xxxx lb
Available: xxxx lb
mbient temperature xxx °F
Tank temperature xxx °F
Tank pressure xxx psi
/C pressure xxx psi
PAG OIL2\DYE Used Oil
xx oz xx oz
FIG. 40
3
FIG. 40
