Snapmaker 3-in-1 3D Printer - Assemble the 3 D Printer; Attach the Feet to the Base Plate

Assemble the 3D Printer
Page 6
3-in-1 3D Printer Quick Start Guide
Screw for Platform
x 4
Heated Bed
x 1
Linear Module
x 1
Attach the Heated Bed to One of the Linear
Modules (Y Axis)
Don’t screw too tight; otherwise, the leveling
will be inuenced.
The screws’ installing position must be the
same as illustrated.
2
Notice
