Assemble the 3D Printer
Page 9
3-in-1 3D Printer Quick Start Guide
Attach the X Axis to the Base Plate
5a
The screws’ installing position must
be the same as illustrated.
M4 x 8 Screw
x 4
Linear Module
x 1
Notice
