Snapmaker Ray - Page 17

Quick Start Guide
|
15
Assembling the Machine
M5 × 12 Screw × 4
H3.0 Hex Key × 1
Ensure that the foot connector is
aligned with the linear module.
04
/37
Attach two foot components to the left Y axis.
