Snapper 7800104 User Manual

0peration
(Continued)
$tarting
and Operation
Engine
(Electric
Start)
IMPORTANT:
When
the ignition
key is turned
to
"START",
the
engine
will turn
over, b'ut will not
start
unless the
Clutch/Brake
pedal
is
pressed
all the way
down,
and the
Blade Lever
is in the
"0FF"
position.
The
operator
should
be
in the
seat.
Start the
engine
as
follows:
1.
Open the
vent
(8,
Figure 2)
on
the
f uel filler
cap
(A)
by
turning
counterclockwise.
IMP0RTANT:
Failure to
open the vent
on the fuelfiller
cap
can
cause the
engine to
stall.
2. Move the
transmission
shift lever
to the
(N)
Neutral
position.
Refer to the
section
entitled
"Wheel
Drive".
IMPORTANT:
D0
NOT
start the engine
with the transmission
shift lever
in
a drive
position.
WARNING
It rs
possible
to
start the engine
with the transmission
shift lever
in a
drive
position.
Follow
starting instructions
caref u lly.
2. Make
certain the
Blade Lever
(A,
Figure
4) is in the
"0FF"
oosition.
Figure
4: Blade lever
(in
'}ff'
position)
3.
Press
the
Clutch/Brake
Pedal
(A,
Figure
5) all the way
down and hold
while
starting the
engine.
5. Move the
engine
speed control
(A,
Figure
6) to the
choke
position
(B)
to
start a cold
engine.
6. Turn
the ignition
key
(A,
Figure 7)
to the
"START"
position
untilthe
engine
starts.
N)TE:
lf
after 5
seconds of
cranking the
engine
does
not
start, release
the key,
make
sure the
Clutch/Brake Pedal
is
fully
depressed,
and
attempt starting
again
after waiting for
ap
p
roxi mately
20
seco nds.
7.
Atter the
engine starts, move the
engine speed control
to the
"FAST"
position
and
allow a brief warm-up
until
engine runs smooth.
Figure
5:
Engaging
the clutch/brake
pedal
_.)/
=$
/
tr/
q
\:-.-l.:___.:s
v
Figure
6.
Engine
speed control
79.
\d%
Figure 7. lgnition key
(Continued
on Next Page)
