C Ignition Switch
OFF
ON
START
D Headlight Switch
E Power Take-Off (PTO)
F Power Take-Off(PTO), Engage
Blades
G Power Take-Off (PTO), Disengage
Blades
H Cruise Control
I Parking Brake Control
J Throttle Control
K Throttle Control SLOW Position
L Throttle Control FAST Position
M Choke
N Fuel Level Gauge (if equipped)
O Ground Speed Pedals
P Seat Adjustment Lever
Q Mower Lift Lever
R Height-of-Cut Switch
S Transmission Release Lever
T Fuel Tank
U Brake Pedal
Electronic Maintenance Display
