snom D7 User Manual Configuring the Function Keys
Fkey numbering system on D375
Function key numbering with 0, 1, 2, or 3 Expansion Modules V2.0 (3xx expansion modules) connected
to the phone. See also "Fkey numbering when D7 is connected to D375" on page 19.
PUI: Phone user interface (Settings > 1 Preferences > 6 Fkeys)
WUI: Web user interface (phone's web interface > page)
fkey idx: XML mass provisioning
Number of Connected 3xx
Expansion Modules
0 1 2 3
fkey idx PUI WUI PUI WUI PUI WUI PUI WUI
Phone 0 1 P1 1 P1 1 P1 1 P1
1 2 P2 2 P2 2 P2 2 P2
2 3 P3 3 P3 3 P3 3 P3
3 4 P4 4 P4 4 P4 4 P4
4 5 P5 5 P5 5 P5 5 P5
5 6 P6 6 P6 6 P6 6 P6
6 7 P7 7 P7 7 P7 7 P7
7 8 P8 8 P8 8 P8 8 P8
8 9 P9 9 P9 9 P9 9 P9
9 10 P10 10 P10 10 P10 10 P10
10 11 P11 11 P11 11 P11 11 P11
11 12 P12 12 P12 12 P12 12 P12
Connected 3xx Exp. Mod. 0 1 2 3
WUI Expansion Module No. 1 2 3 4
(First D7) fkey idx PUI WUI PUI WUI PUI WUI PUI WUI
138 13 1 55 1 97 1 139 1
139 14 2 56 2 98 2 140 2
140 15 3 47 3 99 3 141 3
141 16 4 58 4 100 4 142 4
142 17 5 59 5 101 5 143 5
143 18 6 60 6 102 6 144 6
144 19 7 61 7 103 7 145 7
145 20 8 62 8 104 8 146 8
146 21 9 63 9 105 9 147 9
147 22 10 64 10 106 10 148 10
148 23 11 65 11 107 11 149 11
149 24 12 66 12 108 12 150 12
150 25 13 67 13 109 13 151 13
151 26 14 68 14 110 14 152 14
152 27 15 69 15 111 15 153 15
153 28 16 70 16 112 16 154 16
154 29 17 71 17 113 17 155 17
155 30 18 72 18 114 18 156 18
