Electrical System Parts Breakdown
Model # SP-1875
.ytQ noitpircseD .oN traP yeK
1 rellortnoC 5781 D 6527
2 bonK tekcarB 4216 D
D 6329 1875 Controller Bracket 1
D 6341 Control Power Cable 1
D 6322 1875 Wiring Harness - 25' 1
D 6321 Power Cord - 48" 1
D 6343 Dust Cover 1
D 6344 Dielectric Grease - 1 1/2 oz. (not shown) 1
Special Notes:
1. All external connections must have dielectric grease.
2. Read lead labels before attaching to power source or ground.
3. No other devices may be spliced into wiring harness.
4. Any repairs to wiring harness must be done with heat shrink
butt connectors.
5. If inline fuse is installed, use a 60 amp maxi fuse or circuit breaker.
To Auger Motor
To Vibrator
To Spinner Motor
M O A ov o
a p a o p o
p a ag bo
vo a a
D 6170 Anderson Connector With Leads 1
1
D 6237
5 Terminal Control Power Switch
1
D 6354
3 Terminal Vibrator Switch
Anderson Block
M O D o f h e l A
od c o ll d
