Controller ATyS
CONNECTIONS
39
SOCOMEC - Réf.: 532 214 C
Control circuits
400 Vac (P-P) APPLICATION WITH NEUTRAL CONDUCTOR
CONTACTOR TYPE TECHNOLOGY
13 14 23 24 33 34 43 44 53 54
I1 I2
301 302 303 304 305 306
103
F1, F2
Fuse protection
230 Vac 5 A
LOAD
205
L3
203
L1
106
L1
105
L2
104
L3N
III
O1 O2
GE
L1
L2
L3
1
N
L1
L2
L3
N
2
Cable
RJ45 8/8
ONLY ON ATyS C30
F2F1
ATyS D10 or D20
remote interface
K1
K2
K1
DC-* DC+*
K2
K1 K2
ATYS 438 A GB
Remote interfaces maximum connection
cable (RJ45) = 3 m.
Maximum control cables lenght = 10 m.
In case of longer distance, insert control
relays.
* Only on DC versions.
• Configure the type of control logic in contactor (see
Programming chapter).
• Automatic Power supply 203-205 or 104-106
(see power supply chapter).
