Controller ATyS
CONNECTIONS
ATyS C20/C30
40
SOCOMEC - Réf.: 532 214 C
Control circuits
Electrical operation
Control circuits
400 Vac (P-P) APPLICATION WITH NEUTRAL CONDUCTOR
CIRCUIT BREAKER TYPE TECHNOLOGY
> Electrical interlocking via external control relays
L1
L2
L3
1
N
L1
L2
L3
N
2
F2F1
13 14 23 24 33 34 43 44 53 54
AUXILIARY CONTACT
BRE. 1 BRE. 2
I1 I2
301 302 303 304 305 306
103
F1, F2
Fuse protection
230 Vac 5 A
LOAD
205
L3
203
L1
106
L1
105
L2
104
L3N
III
O1 O2
GE
Cable
RJ45 8/8
ONLY ON ATyS C30
ATyS D10 or D20
remote interface
K1
K2
POS 1
closing
POS 2
opening
POS 2
closing
POS 1
opening
K2
K1
DC-* DC+*
ATYS 439 A GB
Remote interfaces maximum connection
cable (RJ45) = 3 m.
Maximum control cables lenght = 10 m.
In case of longer distance, insert control
relays.
* Only on DC versions.
• Configure the type of control logic in contactor (see
Programming chapter).
• Automatic Power supply 203-205 or 104-106
(see power supply chapter).
