socomec COUNTIS ATd - Technical Characteristics

SOCOMEC - Réf. : 875 452B 9
ENGLISH
Current and voltage connection (max. 10.5mm):
• via terminal-free cable: 25 mm
2
max.
• terminals: from 4 m
2
to 50 mm
2
TECHNICAL CHARACTERISTICS
Operating temperature: -5 up to 45°C
Storage temperature: -20 up to 70°C
PULSE OUTPUTS
OPERATING CONDITIONS
Reed relay 100 V DC - 0.5A - 10 VA
Pulse duration: 60 to 900 ms
Maximum number of operations: 5 x 10
7
/ 10 V DC/10 mA
Fixed pulse value: 100 Wh
Relative humidity: 85 %
Voltage and pulse output connection: 1 to 6 mm
2
(flexible cable)
and 1.5 to 10 mm
2
(rigid cable)
Weight: 700 gr.
Display: 7-digit green LCD
FRONT FACE
INPUTS
CURRENT
Maximum measured current: 80 A
Minimum measured current: 800 mA
Overload:
• permanent: 80 A
• intermittent: 30 Imax / 10 ms
VOLTAGE
Consumption: ≤ 2VA
Active energy accuracy: IEC 61036 / Class 1
EC Marking: EN 50081-2
EN 50082-2
IEC 61000-4/2-3-4-5-6-11
STANDARDS
Environment: IEC 60068-2-6
IEC 60669-1 and 60699-2
CASE
NB:
The Countis ATd is self-supplied via
voltage inputs V1 and V2.
IP index: IP40 (front panel) and IP20 (case)
Dimensions: 7 modules (7 x 18 mm)
Consumption:
• screw-in cables: ≤ 2.5 VA
• terminal-free cables: ≤ 0.1 VA
Measurement range (Ph/Ph):
• 230 V AC ± 15% (230 model)
• 400 V AC ± 20% (400 model)
Frequency: 50/60 Hz ± 2Hz
