socomec COUNTIS E00 - 6 Connection; Connecting the Countis E00;02; Connection to the Electrical Network and to the Loads

10 EN
COUNTIS E00/E02 - 547975A - SOCOMEC
6. CONNECTION
6.1. Connecting the COUNTIS E00/02
LL
NN
4 5
L
L’
40A
N
230 VAC 50/60 Hz
-
+
Solid / Stranded
1.5 mm
2
-> 6mm
2
0.47 in / 12 mm
PZ2
13.28 lb.in /
1.5 Nm max.
Solid / Stranded
0.14 mm
2
->
2.5mm
2
0.27in / 6.9mm
PZ2
4.5 lb.in /
0.5 Nm max.
6.2. Connection to the electrical network and to the loads
The COUNTIS E00/E02 are intended for single-phase networks with neutral.
Pulse output
4: -
5: +
Optocoupler pulse outputs
Terminals 4-5 must be supplied with voltage between 5 and 27
VDC (27 mA max)
Network
L:
: Phase input
L':
: Phase output
N: Neutral connection
LL
NN
4 5
L L’
40A
N
230 VAC 50/60 Hz
-
+
