PULSE OUTPUT
Type Opto-isolated - 5 … 27 VDC 27 mA according to EN62053-31
Pulse weight 100 Wh
DISPLAY
Type 7-digit LCD with backlight
Refresh time 0.5s
Backlight activation time 10s
Active energy: 1 display, 7-digit 000000.0 - 999999.9 kWh
Reactive energy: 1 display, 7-digit 000000.0 - 999999.9 kvarh
Realtime active power: 1 display, 4-digit 00.00 - 99.99 kW
Realtime reactive power: 1 display, 4-digit 00.00 - 99.99 kvar
Realtimevoltage: 1 display, 4-digit 000.0 ... 999.9 V
Realtime current: 1 display, 4-digit 00.00 ... 99.99 A
Power factor: 1 display, 4-digit 0.001-1.000
Frequency: 1 display, 4-digit 45.00-65.00 Hz
SAVING
Energy registers In the EEPROM memory
ENVIRONMENTAL CONDITIONS
Mechanical environment M1
Electromagnetic environment E2
Operating temperature range -25°C to +55°C
Storage temperature -25°C to 75°C
Humidity ≤80%
Installation Internal (box/cabinet)
Vibrations ±0.075 mm
HOUSING
Dimensions W x H x D (mm) Modular - width of 1 module (DIN43880) 18x90x70
Installation On DIN rail (EN 60715)
Connection capacity, tightening torque See chapter "6. Connection", page 10
Protection index Front: IP51 - casing: IP20
Insulation class Class II (EN 50470-1)
Weight 100 g
