4.6. Electrical readings
4.6.1. Measurements
Settings vary by model.
Realtime values Symbol
Unit of
measure
LCD display
Via
communication
Neutral voltage V V
● ●
Current I A
● ●
Power factor PF
● ●
Apparent power S kVA
●
Active power P kW
● ●
Reactive power Q kvar
● ●
Frequency f Hz
● ●
Direction of current
●
Logged data
Total active and reactive energy Ea, Er kWh, kvarh
● ●
Total apparent energy Eap kVAh
●
Total reactive, inductive and capacitive
energy
Er kvarh
●
Total active and reactive energy for each
tariff (T1/T2)
Ea, Er kWh, kvarh
● ●
Total apparent energy for each tariff (T1/T2) Eap kVAh
●
Total reactive, inductive and capacitive
energy for each tariff (T1/T2)
Er kvarh
●
Partial active and reactive energy Ea, Er kWh, kvarh
● ●
Partial apparent energy Eap kVAh
●
Miscellaneous
Current tariff T 1/2
● ●
Partial meters P START/STOP
●
Status of the pulse output
●
Active / inac-
tive
●
