COUNTIS E43/E44 - 547981A - SOCOMEC
11. DIAGNOSTICS MESSAGES
The following messages appear if there are connection or malfunction errors.
11.1. Missing phases
• If one or several phases are not detected, the exclamation point ashes on the screen. Example: phase not
detected
11.2. Reversed phases
• If a 123 phase sequence is detected, the symbol appears.
• If a 132 phase sequence is detected, the
symbol appears.
11.3. Malfunction
• If you see this message, the meter has malfunctioned and must be replaced.

socomec COUNTIS E43 Specifications

General

Type	Energy meter
Display	LCD
Output type	Pulse output
Mounting type	DIN rail
Number of phases	3
Frequency	50/60 Hz
Measurement	Active Energy, Reactive Energy
Current Range	0.5 A to 5 A
Accuracy Class	Class 1
Communication	Modbus
Technology	Digital
