21
COUNTIS E50/E53 - Ref.: 536 419 A
COUNTIS E50/E53
P1
S1
L1
(
R
)
L2
(
S
)
S2 S1 S2 S1 S2S1
I2 I3I1
V1 V2 V3 VN AUX
2
1
2
RÉSEAU BIPHASÉ (2BL)
GB
Two-phase network (2BL)
D
Zweiphasennetz (2BL)
I
Rete bifase (2BL)
NL
Tweefasennet (2BL)
E
Red bifásica (2BL)
P
Rede bifásica (2BL)
N
P1
S1
L1
(
R
)
S2 S1 S2 S1 S2S1
I2 I3I1
V1 V2 V3 VN AUX
2
1
2
GB
Single-phase network (1BL)
D
Einphasennetz (1BL)
I
Rete monofase (1BL)
NL
Enkelfasenet (1BL)
E
Red monofásica (1BL)
P
Rede monofásica (1BL)
RÉSEAU MONOPHASÉ (1BL)
1 Aux.: IEC /CE 110... 400V AC
120... 350V DC
2 Fus.: 0.5 A gG / BS 88 2A gG / 0.5 A class CC
1 Aux.: IEC /CE 110... 400V AC
120... 350V DC
2 Fus.: 0.5 A gG / BS 88 2A gG / 0.5 A class CC
INSTALLATION
2BL
1BL
