COUNTIS E50/E53 - Ref.: 536 419 A
CASE
Dimensions: 97 x 97 x 60 mm
or 97 x 97 x 80 mm with all optional modules (IEC 61554)
Connection: via 2.5 mm
2
disconnectable terminals
(voltage and others) and 6 mm
2
ĺ[HGWHUPLQDOVFXUUHQW
IP index: IP52 (front panel) and IP20 (case)
Weight: COUNTIS E50 : 375 g. - COUNTIS E53 : 380 g.
DISPLAY
Type : backlit LCD display
MEASUREMENTS
Three-phase (3 or 4 wires), two-phase (2 wire) and single-phase networks
VOLTAGE (TRMS)
Direct measurement: from 50 to 520 V AC (phase/phase)
from 28 to 300 V AC (phase/neutral)
Permanent overload: 760 V AC
Update period: 1 second
CURRENT (TRMS)
Via CT with: • Primary: up to 9 999 A
• Secondary: 5 A
Minimum measuring current 3mA si U>28VAC (Ph/N)
Input consumption: < 0.6 VA
Display: from 0 to 11 kA (1.1 times the primary value)
permanent overload: 6 A
intermittent overload: 10 In / 1 second
Update period: 1 second
POWER
Total: 0 to 11 MW/Mvar/MVA
Update period: 1 second
PULSE OUTPUT (COUNTIS E50 and optional on COUNTIS E53)
Reed relays max. 100 V DC - 0,5 A - 10 VA
1RIRSHUDWLRQV œ
8
Galvanic insulation (AC insulation voltage) 2,5 kV
COMMUNICATION RS485 (COUNTIS E53)
RS485 2 or 3-wire 2 or 3-wire half duplex
Protocole JBUS/MODBUS
®
mode RTU
Speed de 2400 à 38400 Bauds
Galvanic insulation 2,5 kV
AUXILIARY SUPPLY IEC/CE
110 to 400 V AC 50/60 Hz ± 10 %
120 to 350 V DC ± 20 %
Consumption < 10 VA
