4.4.3 Structure of the menus on the central bypass cabinet
Load protected by inverter
1 2 3 4 5 6
Load rate:
0
50 100
120
Press "ENTER" to reach the various menus,
Select the menu with the UP
or DOWN key,
Press "ENTER" to reach the various sub-menus,
Select the sub-menu with the UP
or DOWN key,
Validate with the "ENTER" key.
LIST OF MENUS LIST OF SUB-MENUS
t
UPS SYSTEM GENERAL OUTPUT
UPS SYSTEM OUTPUT POWER
MEASUREMENTS "ENTER"4
INVERTER / BYPASS MAINS
UPS AUTOMATIC START UP
LOAD TO MAINS / LOAD TO INVERTER
TRANSFER TO MAINTENANCE BYPASS
UPS COMMANDS "ENTER"4
UPS
UNIT
EVENT LOG "ENTER"4
DIAGNOSTIC CODES
REFERENCES
BYPASS DATA "ENTER"4
UPS SYSTEM STATUS
STATUS "ENTER"4
LOAD TO MAINS / LOAD TO INVERTER
SHUTDOWN UPS OUTPUT
SUBSET COMMAND
"ENTER"4
PROGRAMMING
CLOCK "ENTER"4
LANGUAGE
BUZZER
ACCESS CODE
CONFIGURATION "ENTER"4
LOCAL / REMOTE
PROGRAMMING
u
JBUS LINK "ENTER"4
Note Controls are only displayed when available.
