SPECIFICATIONS
5.1.3. Recommended protection devices
RECOMMENDED PROTECTION DEVICES - Rectifier
(2)
Model MX 250 MX 300 MX 400 MX 500 MX 800 MX 900
D curve circuit breaker
(1)
(A) 630 630 860 1000 1600 1600
RECOMMENDED PROTECTION DEVICES - General bypass
(2)
Model MX 250 MX 300 MX 400 MX 500 MX 800 MX 900
Maximum I
2
t supported by the bypass (A
2
s) 2250000 5120000
Icc max (A) 10600 24700
D curve circuit breaker
(1)
(A) 630 630 800 800 1250 1600
RECOMMENDED PROTECTION DEVICES - Input residual current circuit breaker
(3)
Model MX 250 MX 300 MX 400 MX 500 MX 800 MX 900
Input residual current circuit breaker 300 mA
RECOMMENDED PROTECTION DEVICES - Output
3)
Model MX 250 MX 300 MX 400 MX 500 MX 800 MX 900
Maximum inverter I
2
t at 100 ms
(short-circuit in battery mode) (A
2
s)
256000 256000 400000 841000 1600000
C curve circuit breaker
(4)
(A) 160 160 200 250 400
High-speed fuse
(4)
(A) 400 400 500 700 800
RECOMMENDED PROTECTION DEVICES - Terminals and cable section
Model MX 250 MX 300 MX 400 MX 500 MX 800 MX 900
Rectifier terminals (maximum cable section) Copper bar (3x300 mm
2
) Copper bar (4x300 mm
2
)
Bypass terminals (maximum cable section) Copper bar (3x300 mm
2
) Copper bar (4x300 mm
2
)
Battery terminals (maximum cable section) Copper bar (3x300 mm
2
) Copper bar (4x300 mm
2
)
Output terminals (maximum cable section) Copper bar (3x300 mm
2
) Copper bar (4x300 mm
2
)
(1) For parallel topologies, cables must be selected 1.5 times larger than the recommended size.
(2) Rectifier protection alone should only be considered in the event of separate inputs; if the bypass and rectifier inputs are combined,
the general input protection rating (bypass + rectifier) must reflect the recommended bypass or general protection rating.
(3) must be selective with residual current circuit breakers downstream of the UPS connected to the UPS output. If the bypass
network is separate from the rectifier circuit, or in the event of parallel UPS, use a single residual current circuit breaker upstream
of the UPS.
(4) Selectivity of distribution after the UPS with inverter short-circuit current (short-circuit in battery mode). The rating of the protection
can be increased by “n” times for series-parallel machines, with “n” equal to the number of parallel machines.
