Sodi SR5 - Page 12

SR5 MANUAL
6-2 DISTANCE BETWEEN THE REAR AXLE AND THE MIDDLE OF THE ROUND REAR
EDGE OF THE SEAT.
210mm
(8.27inch)
Measure from the
middle of the
rounded edge
6-3 DISTANCE BETWEEN THE AXIS OF THE LEFT SIDE STUB AXLE FORK AND THE
MIDDLE OF THE REAR ROUNDED EDGE OF THE SEAT.
1015mm
- 11 -
