Sodi SR5 - Front Wheel Height Adjustment

SR5 MANUAL
10.2 ADJUSTMENT OF FRONT WHEEL HEIGHT
DRY TRACK
¾ Place one 4mm spacer on top and one 4 mm + one 2 mm spacer at the bottom (1).
4mm
(1) DRY TRACK
4+2mm
WET TRACK
¾ Place one 4 mm + one 4 mm spacers on top, and one 2 mm spacer at the bottom (2).
¾ The adjustment of dry track (1) can be suitable for wet track.
4+4mm
(2) WET TRACK
2mm
- 19 -
