1.6 Technical data
> Backlit LCD display (dimmable), digit height: 16 mm
> High resolution, non-approvable or approved to Accuracy Class III
> Integrated real-time clock
> Power adapter 100-240 V AC / 50-60 Hz, UK plug adapter (see Accessories), US plug adapter
on demand
> Materials:
Weighing platform: stainless steel
Substructure: stainless or powder-coated steel
Display housing: plastic
> Platform sizes / scales unladen weight:
310(L) x 275(W) x 70(H) mm, unladen weight: 6 kg
400(L) x 300(W) x 75(H) mm, unladen weight: 10 kg
520(L) x 400(W) x 75(H) mm, unladen weight: 20 kg (powder-coated)
520(L) x 400(W) x 105(H) mm, unladen weight: 23 kg (stainless steel)
> Weighing ranges: 3 kg, 6 kg, 15 kg, 30 kg, 32 kg, 35 kg, 60 kg
> Protection class IP 42
> Level adjustment up to 10 mm using the 4 adjustable feet and spirit level
> Nominal operating temperature: -10°C to 40°C
1.7 Startup
> Unpack the scales (please keep the original
packaging for warranty purposes).
> Assemble the scales in a stable level position
at the place of use.
> Remove the cover (look at the spirit level),
and use the adjustable feet and spirit level to
ensure the scales are horizontal.
> After aligning the scales, lock the adjustable
feet.
> Attach the cover again.
> Connect the mains power supply.
> The scales are now ready to use.
1.8 Switching On/Off
Switch the scales on and off using ON/OFF button. Do not load the scales at this point.
Important: Place the weighed items on the scales carefully. Do not keep the platform continuously
loaded. Avoid impacts and loads above the specified weighing range, as these could damage the
scales.
