Soehnle Web Connect Analysis - Start-up Operation Guide

10
2. Start-up operation
2.1 Description of the device
Scale
Web Box






14
15
16
17
18
19
20



10
11
12
13
1. Display
2. Weighing platform
3. Activation key
4. Battery cover
5. Battery compartment
6. Weighing cell
7. Measured value
8. Weak battery
9. Internet connection disrupted
10. Determine data for transmission
11. Data transmission
12. Body fat measurement
13. Measurement unit
14. Power supply socket
15. Reset key
16. Broadband interface
17. Internet connection indicator
18. Network connection indicator
19. Power supply unit
20. Internet cable
