HYD 3000 ... 6000-EP User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd。
- 45 -
↓
Press “Down”
27.S1: 228V 1508ms
↓
Press “Down”
27.S2 threshold 34.5V 200ms
↓
Press “Down”
27.S2: 227V 205ms
↓
Press “Down”
81>.S1 threshold 50.5Hz
100ms
↓
Press “Down”
81>.S1 49.9Hz 103ms
↓
Press “Down”
81>.S2 threshold 51.5Hz
100ms
↓
Press “Down”
81>.S2 49.9Hz 107ms
↓
Press “Down”
81<.S1 threshold 49.5Hz
100ms
↓
Press “Down”
81<.S1 50.0Hz 105ms
↓
Press “Down”
81<.S2 threshold 47.5Hz
100ms
↓
Press “Down”
81<.S2 50.1Hz 107ms
Autotest STD
2.Autotest STD
Press OK to start
The test procedure is same as Autotest Fast, but it’s much more time
consuming.
6. PV Input Mode
6.PV Input Mode
OK
Parallel
OK
Success
Independent
OK
Success
7. EPS Mode
7.EPS Mode
OK
1.EPS Mode Control
OK
1.Enable EPS Mode
OK
2.Disable EPS Mode
1) If PV generation > LOAD consumption
(ΔP > 100W), inverter will charge battery.
2) If PV generation = LOAD
consumption, inverter wont’ charge or
discharge battery.
