HYD 5-20KTL-3PH User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd。
- 10 -
After unpacking the inverter, check whether deliverables are intact and
complete. If any damage is found or any component is missing, contact the dealer.
Table3-1 Components and mechanical parts that should be delivered
NO.
Description
Quantity
1
Inverter
1pcs
2
Rear panel
1pcs
3
PV+ input terminal
4pcs
4
PV- input terminal
4pcs
5
Metal terminals secured
to PV+ input power
cables
4pcs
6
Metal terminals secured
to PV- input power
cables
4pcs
7
BAT- input terminal
2pcs
8
BAT+input terminal
2pcs
9
Metal terminals secured
to BAT- input power
cables
2pcs
10
Metal terminals secured
to BAT+ input power
cables
2pcs
11
M6 Hexagon screws
2pcs
12
M8*80 Expansion bolts used
to secure the wall-mount
bracket to the wall
4pcs
