Sofarsolar HYD KTL-3PH Series - Menu Navigation and Settings

HYD 5-20KTL-3PH User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd。
- 38 -
11
00
France
107
00
Croatia
01
France FAR Arrete23
108
00
Lithuania
12
00
Poland
CAUTION
It’s very important to make sure that you have selected the correct
country code according to requirements of local authority.
Please consult qualified electrical engineer or personnel from electrical
safety authorities about this.
Shenzhen SOFARSOLAR Co., Ltd. is not responsible for any
consequences arising out of incorrect country code selection.
*5.Set battery parameters (Take the default input channel configuration as an
example).Start with battery 1 and work your way up to battery n.
Battery Type
Type of band
communication protocol
Lead acid or no protocol
type
1.Battery Address
1.Battery Capacity
2.Battery Charge Current
Limit
2.Battery Nominal Voltage
3.Battery Discharge
Current Limit
3.Battery Cell Type
4.Battery DOD(EOD)
4.Battery Charge Current
Limit
5.Battery Discharge Current
Limit
6.Battery DOD(EOD)
Table 6-2 Default values for other Settings
Item
The default state
Energy Storage Mode
Self-use mode
EPS Mode
Disable
Anti Reflux
Disable
IV Curve Scan
Disable
Logic interface
Disable
6.3. Menu
Fig 6-1. Main interface
