Sofarsolar HYD KTL-3PH Series - Page 49

HYD 5-20KTL-3PH User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd。
- 44 -
↓
Press “Ok”
Auto Test OK!
↓
Press “Down”
59.S1 threshold 253V 900ms
↓
Press “Down”
59.S1: 228V 902ms
↓
Press “Down”
59.S2 threshold 264.5V
200ms
↓
Press “Down”
59.S2: 229V 204ms
↓
Press “Down”
27.S1 threshold 195.5V
400ms
↓
Press “Down”
27.S1: 228V 408ms
↓
Press “Down”
27.S2 threshold 92V 200ms
↓
Press “Down”
27.S2: 227V 205ms
↓
Press “Down”
81>.S1 threshold 50.5Hz
100ms
↓
Press “Down”
81>.S1 49.9Hz 103ms
↓
Press “Down”
81>.S2 threshold 51.5Hz
100ms
↓
Press “Down”
81>.S2 49.9Hz 107ms
↓
Press “Down”
81<.S1 threshold 49.5Hz
100ms
↓
Press “Down”
81<.S1 50.0Hz 105ms
↓
Press “Down”
81<.S2 threshold 47.5Hz
100ms
↓
Press “Down”
81<.S2 50.1Hz 107ms
Autotest STD
2.Autotest STD
Press OK to start
The test procedure is same as Autotest Fast, but it’s much more time
consuming.
6. Input Channel Config
