HYD 5-20KTL-3PH User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd。
- 46 -
8. Communication Addr
8.Communication Addr
OK
1.Communication Addr
OK
2.Baud Rate
OK
6.3.2 Advanced setting
2.Advanced setting
OK
Input 0001
1.Battery Parameter
2.Anti Reflux
3.IV Curve Scan
4.Logic interface Control
5.Factory Reset
6.Parallel setting
7.Bluetooth Reset
8.CT Calibration
1. Battery Parameter
1.Battery Parameter
OK
Battery Parameter1
OK
Battery Parameter2
OK
A.Inner BMS
1.Battery Parameter
OK
1.Battery Type
5.Max Charge (A)
2.Battery Capacity
6.Max Discharge (A)
3.Nominol Bat Voltage
7.*Discharg Depth
4.Battery Cell Type
8.Save
OK
B.PYLON/SOFAR
1.Battery Parameter
OK
1.Battery Type
4.Max Discharge (A)
2.Battery Address
5.Discharg Depth
3.Max Charge (A)
6.Save
OK
Depth of Discharge
For example: if Discharge Depth = 50% & EPS Discharge Depth = 80%.
While grid is connected: Inverter won’t discharge the battery when its SOC is
less than 50%.
In case of blackout: Inverter will work in EPS mode (if EPS mode is enabled)
& keep discharging the battery till battery SOC is less than 20%.
7.Depth of Discharge
OK
Discharge Depth
50%
EPS Discharge Depth
80%
