SOFAR 60-80KTLX-G3 User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd.
Inverter is heavy, attention to keep the balance when lift the inverter.
Dropped while being transported may cause injuries.
Do not put the inverter with wiring terminals contacting the floor
because the power ports and signal ports are not designed to support
the weight of the inverter
When place inverter on the floor, put it above foam or paper to avoid
the damage of the shell of inverter.
4.6. Installation
4.6.1 Installed on wall
：
Step 1: Placed the rear panel on the mounting wall, determine the mounting height
of the bracket and mark the mounting poles accordingly. Drilling holes by using
Hammer Drill, keep the hammer drill perpendicular to the wall and make sure the
position of the holes should be suitable for the expansion bolts.(Note: Please find
M8*80 expansion bolt in the package)
Figure 4-6 Drilling holes on the mounting wall
Step 2: Insert the expansion bolt vertically into the hole；
