Softing dataFEED Series - 6.3 Firmware Update; 6.4 Backup and Restore

© Softing Industrial Automation GmbH 33
Chapter 5 - Machine Settings
<DataType>
Syntax
Syntax R
Syntax
E / A
Syntax
ER
With Array
Meaningful
Suffixes
BIT
VT_BOOL
X
RX5.2
HRX5.2
4X5.2
E255
I255
DE255
DI255
125543
----
----
----
INT ****
VT_I2
(signed)
None
I
R50
HR50
400050
RI50
HRI50
4I50
----
ER120
IR120
312034
ERI120
IRI120
3I12034
R50.2
HR50.2
400050.2
ER120.2
IR120.2
312034.2
BCD
BA
WORD ****
VT_UI2
(unsigned)
W
RW50
HRW50
4W50
----
ERW120
IRW120
3W12034
RW50.2
HRW50.2
4W00050.2
ERW120.2
IRW120.2
3W12034.2
BCD
BA
DOUBLE INT
****
VT_I4
(signed)
D
DI
RD50
HRD50
4D50
RDI50
HRDI50
4DI50
----
ERD120
IRD120
3D12034
ERDI120
IRDI120
3DI12034
RD50.2
HRD50.2
4D00050.2
ERD120.2
IRD120.2
3D12034.2
BCD
BA
DOUBLE WORD
****
VT_UI4
(unsigned)
DW
RDW50
HRDW50
4DW50
----
ERDW120
IRDW120
3DW12034
RDW50.3
HRDW50.3
4DW50.3
ERDW120.3
IRDW120.3
3DW12034.3
BCD
BA
REAL
VT_R4
R
RR5
----
ERR5
RR5.3
ERR5.2
----
DOUBLE
VT_R8
RD
RRD5
----
ERRD5
RRD5.10
----
STRING
VT_BSTR
S
RS5.4
----
ERS5.4
----
----
* if only standard types has been selected as data types (server settings)
** if also unsigned has been selected as data types (server settings)
*** with suffix WDT (Wago Date and Time) 4 registers (8 bytes) are read
**** It depends on the manufacturer which byte is given as first or second of the Word / Double Word. It is
possible to create two connections: (1) One for Word /Double Word access and possibly the Word Swap option
(depending on the Double Word implementation of the Modbus terminal).
(2) One for Byte access and the Byte Swap option.
