Chapter 3 - PBpro ETH Administration
22
PBpro ETH - User Guide
c. Open Network and Sharing Center.
d. Click Local Area Connection.
e. In the Connection Status window click Properties.
f. In the item connection list select Internet Protocol Version 4 (TCP/IPv4).
g. Click Properties.
h. In the General dialog, the regular (first) IP address, the subnet mask and the
standard gateway are shown.
i. Click Advanced to add a second IP address. Then click Add in the IP Addresses
dialog.
j. Enter the IP address and the subnet mask.
k. Click Add.
l. Then confirm all open dialogs with [OK].
Assign a second (local) IP address under Windows XP
a. Select Start Settings Control Panel. Double-click the icon Network and
Dial-up Connections.
b. Double-click LAN connection.
c. Click Properties.
d. Select the entry Internet Protocol (TCP/IP) and click Properties.
e. In the Internet Protocol (TCP/IP) Properties dialog, the regular (first) IP address,
the subnet mask and the standard gateway address are shown. To add a second
IP address click the "Advanced..." button.
f. Click Advanced to add a second IP address. Then click Add in the IP Addresses
dialog.
g. Enter the IP address and the subnet mask.
h. Click Add.
i. Then confirm all open dialogs with [OK]
These settings are only available if DHCP is disabled.
3. Try to ping the PBpro ETH. Open a command prompt and enter the following
command: "ping 192.168.212.212". The PBpro ETH should respond.
If it does not respond, check whether the PBpro ETH is correctly connected to the LAN
and whether it is switched on. Check also whether your computer is correctly
connected to the LAN by a cable. Check whether the computer has been configured
with a valid IP address from the subnet 192.168.212.0. Try to ping the second (local)
IP address of your computer (in the example, 192.168.212.211). If the local computer
does not respond, the second IP address has not been initialized correctly.
4. If you have access to the PBpro ETH from your computer, you can change its network
configuration with a Web browser.
