Chapter 4 - Technical Data
32
PBpro ETH - User Guide
4 Technical Data
The following summary provides you with the most important technical data:
Order Code
(product including
device, CD, manual)
DEL-NN-
012311
DEL-NN-
012312
DEL-NN-
012313
DEL-NN-
012314
Number of PROFIBUS
Channels
1
2
3
4
Part Number
(of the device itself)
DEA-NN-
012311
DEA-NN-
012312
DEA-NN-
012313
DEA-NN-
012314
Supply Voltage
(direct current)
+24V DC
Supply Voltage
Tolerance
±20% (incl. ripple)
Typical Current Consum
ption During Operation
0.2 A
0.3 A
0.4 A
0.5 A
Mounting
TS35 DIN carrier rail (EN 50022)
Dimensions (W x H x D
in mm)
47 x 134 x
111
111 x 134 x 111
Weight (approx. in kg)
0.3
0.6
0.7
0.8
Degree Of Protection
IP 20
Ambient Temperature
(operation)
0°C to 55°C
Ambient Temperature
(storage)
-20°C to 70°C
Relative Air Humidity
max. 90% at +25°C (non-condensing)
