Chapter 3 - PBpro ETH Administration
26
PBpro ETH - User Guide
Click Download Firmware and Reboot to start the download process. Firmware
download and flash memory update take between one and two minutes. The successful
completion of the update process is indicated by the message Success in the browser
window.
3.3.4.5
Set password
This web page allows for changing the password. Enter the current password first. Then
enter the new password twice.
3.3.5 Configuring access to PBpro ETH on a Windows PC
3.3.5.1
Install software
The PBpro ETH software is part of the "PBpro ETH Installation CD".
1. Insert the CD into your CD drive.
2. If Autorun is enabled on your system, the startup page is opened automatically.
3. If Autorun is disabled, open an Explorer window, select your CD drive and double-click
the file start.exe.
The CD contains various information and software. Make sure to install at least the
"Drivers and Software Development Kit (SDK) for Windows".
3.3.5.2
Configure driver
Before application programs can use PBpro ETH, you need to configure the device for
operation:
1. Click Start All Programs Softing PROFIBUS Drivers and API
Runtime System Driver Configuration.
