16 | GETTING STARTED
Equalizer Section
EQ activation Activates or bypasses the
equalizer section.
Low Band
Cut/Bell/Shelf Sets the operating mode of the
equalizer’s low band.
Frequency Sets the operating frequency
of the equalizer’s low band.
Low Gain Turned clockwise from its
center position, boosts the gain
of the equalizer’s low band.
Turned counterclockwise
from its center position, cuts
the gain of the equalizer’s low
band.
Low Mid Band
Q Sets the width of the equal-
izer’s low mid band.
Frequency Sets the operating frequency
of the equalizer’s low mid
band.
Low Mid Gain Turned clockwise from its
center position, boosts the
gain of the equalizer’s low mid
band. Turned counterclockwise
from its center position, cuts
Low Band Low Mid Band
EQ activation
