Instruction Manual INOXA SERIES
GB
English
GB
Chap.Par. DESCRIPTION Page
Introduction 2
Ordinary maintenance 2
1. Possible applications 2
2. General precautions 3
3. Emergency electrical normatives 3
4. Emergency anti-fire normatives 3
5. Main line connections 3
6. Commands description 4
7. ELECTRODE installation 6
7.1 ELECTRODE holder connection 6
7.2 Ground cable connection 6
7.3 ELECTRODE mode selection 7
7.4 Remote control regulation 7
7.5 “VRD” function activation
(Voltage Reduction Device) 7
8. TIG installation 8
8.1 TIG torch connection 8
8.2 Ground cable connection 8
8.3 Filling of Cooler Unit
(optional) 8
8.4 Cooler Unit connection
(optional) 9
8.5 Installation on 2 / 4 wheels Trolley
(optional) 9
8.6 TIG mode selection 10
8.7 HF / LIFTARC ignition 10
INDEX
Chap.Par. DESCRIPTION Page
8.8 TIG DC operation
2 TIMES CYCLE / 4 TIMES CYCLE 11
8.9 UP SLOPE and DOWN SLOPE
regulation 13
8.10 TIMER setting (only on HFP series) 13
8.11 Secondary parameters regulation
(only on HFP series) 14
8.12 TIG PULSATION (only on HFP series) 15
8.13 JOBS uses (only on HFP series) 15
8.14 POST GAS time setting
(only on INOXA HF series) 16
8.15 Remote control regulation 17
9. Warning signals 18
10. Technical Specifications 19
11. Spare parts list 20
Electrical schematics 25
