SOLAR ELECTRONICS COMPANY
Test Results
During the investigation several other test configurations were evaluated using existing as well as some
newly developed equipment. The configuration of each test setup is diagramed and the equipment
involved is identified or described in Configuration 1 through 3, and the plotted short circuit current
waveforms are shown in Figures 1 through 5.
Test Configuration 1
Standard setup
Test Configuration 2
Use of Type 6220-4
