Connecting PV Strings (Option 2)
8
Combiner
Box
Important: When installing a system with
more than 3 strings per a single Synergy Unit
(whether connected directly or via a combiner
box), fuses are required. In SolarEdge system,
25A fuses shall be used
Max 2 AWG
-
4 AWG: 3.7 lb.*ft
3 – 2 AWG: 5.9 lb.*ft
Ground conduit nut if
required by regulation
Synergy Units
Left Center Right
Left Center Right
2.2 lb.*ft.
4-14 AWG
+
DC-
DC+
Fine stranded
Ferrule
To Next Page
