SolarEdge SE K Series - IMPORTANT SAFETY INSTRUCTIONS; Safety Symbols Information

MAN-01-00786-1.3 5
Maintaining Clearance
3
40 cm / 16”
10 cm / 4”
114.5 cm / 45”
100.8 cm / 39.68”
CAUTION! Donot block Airflow
WARNING! Area
in front of the
inverter must be
kept clear for at
least one meter
!
20 cm / 8”
30 cm / 11.8”
Back to back
On metal back sheetOn mesh fence
Indoor Clearance
Outdoor Clearance
20 cm / 8” where annual average high temperature equals or above 25˚C / 77˚F
Keep more than 10°
Horizontal Installation
15 cm / 6”
5 cm / 2”
40 cm / 16”
40 cm / 16”
