SolarEdge SE4000 User Manual

 SE4K SE5K SE7K SE8K SE9K SE10K SE12.5K Unit
Additional Features
Supported
communication
interfaces
(1)
RS485, Ethernet, ZigBee (optional), Wi-Fi (optional), Built-
in GSM (optional)

Smart Energy
Management
Export Limitation, Home Energy Management 
Arc Fault Protection Integrated, user configurable (according to UL1699B) 
Standard Compliance
Safety IEC-62103 (EN50178), IEC-62109 
Grid connection
standards
(2)
VDE 0126-1-1, VDE-AR-N-4105, AS-4777, G83 / G59 
Emissions
IEC61000-6-2, IEC61000-6-3, IEC61000-3-11, IEC61000-3-
12,
FCC part15 class B

WEEE, RoHS Yes 
Installation Specifications
AC output / Gland
Diameter / Wire Cross
Section
15-21 mm / Solid wire 2.5-16 mm
2
, Stranded wire 2.5 - 10
mm
2

DC input
2 MC4 pairs
(3)

Dimensions (WxLxH) 540 x 315 x 260 mm
Weight 33.2 kg
Operating
temperature range
(4)
-20 - +60 (M40 version -40 to + 60) °C
Operating humidity –
non condensing
< 95 %
Cooling Fan (user replaceable) 
(1)
Refer to Datasheets > Communications category in Downloads page for specifications of optional communication
options: http://www.solaredge.com/groups/support/downloads
(2)
For all standards refer to the Certifications category in
http://www.solaredge.com/groups/support/downloads.
(3)
You can connect strings in parallel to a single input as long as the cumulative current does not exceed 45A.
(4)
For inverter power de-rating refer to the application note at the following link:
http://www.solaredge.com/files/pdfs/se-temperature-derating-note.pdf
Technical Specifications - Three Phase Inverters (Europe &APAC) 107
Three Phase System Installation Guide MAN-01-00057-4.1

SolarEdge SE4000 Specifications

General

Model	SE4000
Manufacturer	SolarEdge
Rated AC Power	4000 W
CEC Weighted Efficiency	97.5%
Number of MPP Trackers	1
Protection Rating	IP65
Cooling	Natural Convection
Warranty	12 years
AC Output Power	4000 W
AC Voltage	220 / 230 / 240 Vac
Max. DC Input Power	5400 W
Operating Temperature Range	-25°C to 60°C
