SolarEdge SE5000 User Manual

Inverter Configuration – Setup Mode
You can configure the inverter using one of the following:
The internal LCD user buttons. When using this option, the inverter cover is
removed.
The external LCD light button. When using this option, removing the inverter
cover is not required. This option of configuration includes a less detailed set of
menus.
Configuring the Inverter Using the Internal LCD User Buttons
After inverter installation, an installer may perform basic system configuration.
Configuration is done when the inverter is in Setup mode.
To enter Setup mode:
1.
Turn the inverter ON/OFF switch to OFF (AC remains ON).

WARNING!
If the inverter was operating properly (power was produced by the power
optimizers), the following message is displayed.
D C V O L T A G E N O T S A F E
D O N O T D I S C O N N E C T
V D C : 7 2 . 0
This message is displayed until the DC voltage is safe (50V). Do not open the
cover until the voltage is safe or until at least five minutes have passed.
2. Press the Enter button for at least 5 seconds. The following message is displayed:
P l e a s e e n t e r
 P a s s w o r d
* * * * * * * *
3. Use the three rightmost internal LCD user buttons to type in the following password:
12312312. The following menu is displayed:
C o u n t r y < I t a l y >
L a n g u a g e < E n g >
C o m m u n i c a t i o n
P o w e r C o n t r o l
D i s p l a y
M a i n t e n a n c e
I n f o r m a t i o n
-Three Phase System Installation Guide MAN-01-00057-4.1
46 Inverter Configuration – Setup Mode

SolarEdge SE5000 Specifications

General

Model	SE5000
Manufacturer	SolarEdge
Category	Inverter
AC Output Power	5000 W
Efficiency	98.3%
Cooling	Natural convection
Protection Rating	IP65
Rated AC Power	5000 W
Max. AC Power	5000 VA
Maximum Input Voltage	480 V
Number of MPP Trackers	1
Max. Input DC Voltage	480 V
Operating Temperature Range	-25°C to 60°C
AC Voltage	230 V
