SolaX Power X1-Hybrid-5.0-D User Manual

36
37
Diagram B: Neutral line and PE line are separated from each other,
all loads connect to the Off-grid port;(For most countries)
Diagram C: Neutral line and PE line are combined togeter, and the
common load is connected to the off-grid port;(Apply to Australia)
Electrical Connections
Electrical Connections
X1-Matebox
CT
Distrbution Box
Battery
Grid
Off-grid
PV 1PV 2
E-BAR
Grid
Breaker
Loads
N-BAR for loads
N
Main Breaker
BAT
X1-Hybrid G4
PE
N
BAT
Battery
N-BAR for loads
N-BAR for off-grid loads
off-grid loads
Loads
X1-Hybrid G4
PV 1
PV 2
E-BAR
RCD
Breaker
Grid
Breaker
Grid
Off-grid
Main Breaker/RCD
Breaker
Breaker
CT
CT
Breaker
RCD
X1-Hybrid G4 series inverter has an off-grid function. When the grid is
connected, the inverter outputs go through the Grid port, and when the grid
is disconnected, the inverter outputs go through the Off-grid port.
The Off-grid function can be connected to part of the load, and it can also be
used to connect to all loads. Please refer to the following diagram for the
wiring .
To be compatible with all loads,you will need an addition a accessory. If you
need a solution, please contact our sales.
For to different local wiring rules, please refer to the diagram below
Please select the appropriate wiring method according to local wiring rules.
Off-grid wiring diagram
Ø
Diagram A: Neutral line and PE line are separated from each other, and the
common load is connected to the off-grid port;(For most countries)
5.3 Off-grid Bolck Diagram
N
BAT
Battery
N-BAR for loads
N-BAR for off-grid loads
off-grid loads
Loads
X1-Hybrid G4
PV 1
PV 2
E-BAR
RCD
Breaker
Grid
Breaker
Grid
Off-grid
Main Breaker
Breaker
Breaker
CT
CT
Breaker
PE
RCD
